SINGLE STAGE AIR COMPRESSOR

( Maximum Pressure 9 Kg/Cm2 or 128 PSI )

HAWA Cylinder Motor Power Piston Displacement Tank Capacity Compressor
Model Size HP KW LPM CFM LITRES RPM
HCSC 5 57 0.5 0.75 50 1.7 45 750
HCSC 10 63 1 1 100 3.5 70/90 850
HCSC 15 63 1.5 1.1 144 5.1 110 925
HCSC 20 63*63 2 1.5 240 8.5 160 850
HCSC 50 70*70 5 3.7 59 21.1 250 925
HCSC 100 100*100 10 7.5 1220 43.1 420 925
HCSC 150 100*100*100 15 11 1871 66.1 500 925
